Nanocrystalline graphite films nucleation by the radio frequency bias pretreatment.
Abstract
New method for nucleation of different nanocrystalline carbon films upon monocrystalline Si substrate was proposed. The process is based on a combination of microwave and radio frequency plasma assisted chemical vapor deposition methods. Potential of the method for nucleation was demonstrated by deposition of nanocrystalline diamond film in pure microwave plasma in one process, immediately after "seeding" procedure. The method was also used for growth of nanocrystalline graphite (NCG) films, which are currently under intensive investigation due to their exceptional electronic properties, particularly fine electron emission characteristics. Deposited NCG films have demonstrated remarkable electron field emission properties having current density of up to 10 A/cm2. The films have also possessed good adhesion to silicon substrate. Carbon films and nucleation layer were characterized by scanning electron microscopy, transmission electron microscopy and Raman spectroscopy.
AI evidence extraction
Main findings
A method combining microwave and radio frequency plasma assisted chemical vapor deposition was proposed for nucleation of nanocrystalline carbon films on monocrystalline Si. The approach was demonstrated by depositing nanocrystalline diamond after an RF "seeding" procedure and was also used to grow nanocrystalline graphite films with reported electron field emission current density up to 10 A/cm2 and good adhesion to silicon.
Outcomes measured
- Nucleation of nanocrystalline carbon films on monocrystalline Si substrate
- Growth/deposition of nanocrystalline diamond film
- Growth/deposition of nanocrystalline graphite (NCG) films
- Electron field emission properties (current density up to 10 A/cm2)
- Adhesion of films to silicon substrate
- Material characterization by SEM, TEM, Raman spectroscopy
Limitations
- No frequencies, power levels, or exposure parameters for the microwave/RF plasma are provided in the abstract.
- No quantitative comparison group or baseline is described in the abstract.
- No sample size or replication details are reported in the abstract.
