Definition and Validation of an Exposure Measurement Method for a Typical Load of a Base Station

Abstract

Category: Exposure Assessment Tags: EMF, exposure measurement, base stations, 5G, risk communication, mobile radio, massive-MIMO DOI: 10.1002/bem.70029 URL: pmc.ncbi.nlm.nih.gov Overview In the context of risk communication regarding mobile radio, a significant discussion has surfaced about whether actual exposure at common load of a base station should be reported in addition to the theoretical maximum, especially as 5G massive-MIMO becomes more widespread. However, there has been no reproducible method available for measuring instantaneous exposure, independent of cell utilization. To address this gap, the study identified 10 mobile phone use cases, measured their corresponding data rates, and categorized them into low (20 Mbps), medium (200 Mbps), and high (600 Mbps) to simulate a typical base station load. Methodology - A measurement method was developed using iPerf on user equipment to generate target data rates at the measurement point. - Channel power measurements were used to determine exposure across all installed mobile radio services. - The method was validated at four base stations, considering factors such as number of users, averaging time, and buffering. Findings - The method proved reliable across varying times of day and base station loads. - Averaging over 30 sweeps produced reproducible exposure results. A comparison of instantaneous exposure during actual application usage versus using iPerf to provoke constant data rates showed that only 5 out of 48 examined cases in 5G scenarios had deviations exceeding the expanded uncertainty. Only two cases showed a deviation in total exposure greater than 3 dB. This demonstrates that provoking a constant data rate with iPerf is equivalent, in terms of exposure, to typical real-world scenarios, regardless of user data buffering. Conclusion The proposed method enables feasible and reproducible measurement of instantaneous exposure under typical base station load conditions. This supports improved risk communication by reporting both typical and maximum exposures. The integration of this approach into standards like IEC 62232:2022 is discussed, with the method providing a useful and robust exposure measurement technique relevant for regulation and public health. Important EMF Health Risk Note: Accurate and reproducible measurement methods for electromagnetic field (EMF) exposure, particularly under real-world load conditions, are fundamental for assessing and communicating the potential health risks associated with base station emissions. Validated exposure assessment helps inform safety guidelines and enables transparent communication of possible connections between EMF and health outcomes.

AI evidence extraction

Main findings

A reproducible method was developed to measure instantaneous exposure independent of cell utilization by provoking target data rates (low/medium/high) using iPerf and performing channel power measurements across installed mobile radio services. Validation at four base stations indicated the method was reliable across varying times of day and base station loads, with reproducible results achieved by averaging over 30 sweeps. In a comparison of real application usage versus iPerf-provoked constant data rates, 5 of 48 examined cases in 5G scenarios exceeded the expanded uncertainty, and only two cases showed a deviation in total exposure greater than 3 dB.

Outcomes measured

• Reproducibility/reliability of an instantaneous EMF exposure measurement method under typical base station load
• Agreement between exposure measured during real application usage vs iPerf-provoked constant data rates (5G scenarios)
• Effect of averaging (number of sweeps) on reproducibility
• Validation across different base station loads/times of day and factors (number of users, averaging time, buffering)

Limitations

• Frequency band(s) and quantitative exposure levels are not reported in the abstract
• Number of base stations is given (four), but overall sample size for measurements and detailed protocol parameters are not fully specified in the abstract
• Health outcomes are not assessed; the study focuses on exposure measurement methodology

Suggested hubs

• who-icnirp (0.42)
  Discusses integration into IEC 62232:2022 and relevance for regulation/safety guideline communication for base-station exposure.
• 5g-policy (0.38)
  Focuses on 5G massive-MIMO base stations and reporting typical vs maximum exposure for risk communication.

{
    "study_type": "exposure_assessment",
    "exposure": {
        "band": null,
        "source": "base station",
        "frequency_mhz": null,
        "sar_wkg": null,
        "duration": null
    },
    "population": null,
    "sample_size": null,
    "outcomes": [
        "Reproducibility/reliability of an instantaneous EMF exposure measurement method under typical base station load",
        "Agreement between exposure measured during real application usage vs iPerf-provoked constant data rates (5G scenarios)",
        "Effect of averaging (number of sweeps) on reproducibility",
        "Validation across different base station loads/times of day and factors (number of users, averaging time, buffering)"
    ],
    "main_findings": "A reproducible method was developed to measure instantaneous exposure independent of cell utilization by provoking target data rates (low/medium/high) using iPerf and performing channel power measurements across installed mobile radio services. Validation at four base stations indicated the method was reliable across varying times of day and base station loads, with reproducible results achieved by averaging over 30 sweeps. In a comparison of real application usage versus iPerf-provoked constant data rates, 5 of 48 examined cases in 5G scenarios exceeded the expanded uncertainty, and only two cases showed a deviation in total exposure greater than 3 dB.",
    "effect_direction": "unclear",
    "limitations": [
        "Frequency band(s) and quantitative exposure levels are not reported in the abstract",
        "Number of base stations is given (four), but overall sample size for measurements and detailed protocol parameters are not fully specified in the abstract",
        "Health outcomes are not assessed; the study focuses on exposure measurement methodology"
    ],
    "evidence_strength": "moderate",
    "confidence": 0.7800000000000000266453525910037569701671600341796875,
    "peer_reviewed_likely": "yes",
    "keywords": [
        "EMF",
        "exposure measurement",
        "base stations",
        "5G",
        "risk communication",
        "mobile radio",
        "massive-MIMO",
        "iPerf",
        "channel power",
        "IEC 62232:2022"
    ],
    "suggested_hubs": [
        {
            "slug": "who-icnirp",
            "weight": 0.419999999999999984456877655247808434069156646728515625,
            "reason": "Discusses integration into IEC 62232:2022 and relevance for regulation/safety guideline communication for base-station exposure."
        },
        {
            "slug": "5g-policy",
            "weight": 0.38000000000000000444089209850062616169452667236328125,
            "reason": "Focuses on 5G massive-MIMO base stations and reporting typical vs maximum exposure for risk communication."
        }
    ]
}
